热转印条码打印机
● 兼容ZPL EPL TSPL 语言
● 小巧结构方便摆放
● 大容量内存支持多矢量字体下载打印
● 支持100米小卷芯色带
● 全接口可适应各种应用场合
● 可选配蓝牙模块 配合手机app直接打印
详情页面
规格
配件
视频指南
下载
| 打印机型号 | iT888 | |
|---|---|---|
| 分辨率 | 203dpi | |
| 打印方式 | 热转印 | |
| 最大打印速度 | 6ips | |
| 最大打印宽度 | 4.25"(108mm) | |
| 最大打印长度 | 51"(1296mm) | |
| 物理尺寸（宽 x 高 x 深） | 12.12"(308mm)x9.84"(250mm)x7.09"(180 mm) | |
| 重量 | 5.27lbs (2.9kg) | |
| 处理器 | 32-bit RISC CPU | |
| 存储 | 16 MB Flash /32 MB RAM | |
| 接口 | Standard: USB-B and Ethernet 10/100Base T,RS-232 Serial portOptional: Bluetooth 5.2/BLE(Factory option) | |
| 电源 | External universal switching power supplyInput: AC 100~240V, 2.0A, 50~60 HzOutput: DC 24V 2A, 48W | |
| 用户界面 | 1operation button( feed )1 LED with 3 colors | |
| 传感器 | Gap transmissive sensorBlack mark reflective sensor (position adjustable)Head open sensor | |
| 内部字体 | 8 resident expandable ZPL II bitmap fontsSimplified Chinese, Traditional ChineseDownloadable objects include graphics, scalable and bitmap fonts, label templates and formatsIBM Code Page 850 international character sets are available in the fonts A, B, C, D, E, F, G and 0 through software controlCode Page 1250, 1251, 1252, 1253, 1254, 1255, 1256 Support with font 0 | |
| 图形格式 | PCX,BMP | |
| 条码类型 | 1D: Code 39, Code 93, Code 128UCC, Code 128 subset A, B, C, Codabar, Interleave 2 of 5, EAN-8, EAN-13, EAN-128,UPC-A, UPC-E, EAN and UPC 2 (5) digits add-on, MSI, GS1 DataBar2D:PDF417, Maxicode, DataMatrix, QR Code, Aztec | |
| 字体和条形码旋转 | 0, 90, 180, 270 degree | |
| 打印机语言 | ZPL-II, TSPL, DPL, EPL2 | |
| 打印介质类型 | Continuous, die-cut, black mark, fan-fold, notch | |
| 打印介质类型 | Standard: Continuous, Tear-Off | |
| 打印介质宽度 | Min 1"(25.4mm) / Max 4.64"(118mm) | |
| 打印介质厚度 | 0.002"(0.06mm) to 0.010"(0.250mm) | |
| 打印介质纸筒直径 | 0.5"(12.7mm)/ 1"(25.4mm) | |
| 纸仓支持最大纸卷外径 | 5.0"(127mm) | |
| 打印介质长度 | Min.: 0.24"(10mm)Max.: 51"(1296mm) | |
| 色带类型 | Wax, Wax/Resin, Resi | |
| 色带长度 | 328.1 ft(100m) | |
| 色带核心直径 | 0.5"(12.5mm) | |
| 色带宽度 | Min 1.18"(30mm) / Max 4.33"(110mm) | |
| 环境条件 | Operating Temperature: 41° to 104°F (5° to 40°C) (limitations based on selected media) / Operating Humidity: 25 to 85% RH Non-CondensingStorage Temperature: -20° to 122° F (-20° to 50° C) / Storage Humidity: Non-Condensing | |
| 安全认证 | CCC, FCC, CE, CB, Energy Star | |
| 环境条件 | RoHS | |
| 选项 | Bluetooth 5.2/LE(Factory option) |
蓝牙
切刀模组
